AMD Ryzen 7 9800X3D vs. Ryzen 7 5800X3D in Battlefield 6: CPU Benchmark Results

Battlefield 6 multiplayer testing highlights consistent CPU performance differences when comparing Ryzen 7 5800X3D, Ryzen 7 9800X3D, and Intel processors.

Hardware by Nakiro on Aug 20, 2025

After more than a month of testing, we revisited Battlefield 6 with a focus on CPU performance, adding in Ryzen 7 5800X3D after plenty of feedback that its absence in earlier tests was unacceptable. Alongside that, we took another look at Ryzen 7 9800X3D against Intel’s Core Ultra 265K to address criticisms of our testing methodology.

Benchmarking a dynamic multiplayer title like Battlefield 6 is a challenging task, and we wanted to show why accurate, consistent testing is far from simple.

AMD, Ryzen 7 9800X3D, Ryzen 7 5800X3D, Battlefield 6, CPU Benchmark Results, NoobFeed

The Challenge of Multiplayer Testing

To properly measure CPU performance in Battlefield 6, the only reliable way is to test in the same match with identical scenarios. Variance between matches can be as high as 20%, even when trying to replicate the same actions. That means the traditional method of swapping CPUs between runs isn’t accurate enough.

To counter this, we set up two test systems with identical GPUs, storage, and hardware. Both systems were loaded into the same match, following each other closely to create apples-to-apples comparisons.

This method is difficult to execute, especially when one person has to control both PCs, but with help, we achieved consistent results.

Test Configuration

Ryzen 7 5800X3D was paired with DDR4-3600 CL14 memory, while Ryzen 7 9800X3D ran with DDR5-6000 CL30. Both CPUs were tested alongside an RTX5090 to reduce GPU bottlenecks and highlight CPU performance.

1080p Ultra: 5800X3D vs 9800X3D

At 1080p ultra, Ryzen 7 9800X3D delivered a 36% higher average frame rate at the start of testing, with 25% stronger 1% lows. Moving through objectives, the margins remained consistent, with 9800X3D averaging 27–34% faster performance and 1% lows, 21–43% higher.

Even in heavy action, where firefights caused chaotic performance swings, 9800X3D consistently pulled ahead by around 35% on average with over 40% stronger 1% lows. Ryzen 7 5800X3D ended up comparable to Ryzen 7 9700X and Intel Core Ultra 7 265K under CPU-limited conditions.

AMD, Ryzen 7 9800X3D, Ryzen 7 5800X3D, Battlefield 6, CPU Benchmark Results, NoobFeed

1440p Ultra: 5800X3D vs 9800X3D

At 1440p, GPU limitations narrowed the gap initially, with 9800X3D being just 6% faster in average frame rate but 18% better for 1% lows. However, as gameplay unfolded, 5800X3D fell behind more significantly. Eventually, 9800X3D led by 25% in averages and 30–40% in 1% lows.

This demonstrated how 9800X3D scales better as the CPU becomes more involved in heavier moments of gameplay.

4K Ultra: 5800X3D vs 9800X3D

At 4K ultra, performance became GPU-limited, with both CPUs achieving nearly identical average frame rates. Still, 9800X3D showed around 10% stronger 1% lows, giving smoother consistency.

Addressing Testing Criticism

Some users on Reddit argued our methodology was flawed compared to the work done by PC Games Hardware. Their approach involved loading into random matches and benchmarking contested objectives. The problem with this method is that no two matches play out the same way, making run-to-run comparisons unreliable.

The only accurate way is to benchmark multiple CPUs in the same match, under identical conditions. Anything else risks comparing entirely different workloads. This is why we stress the need for simultaneous system testing, despite the difficulty.

Revisiting 9800X3D vs Core Ultra 265K

Our previous data showed 9800X3D outperforming Core Ultra 265K by 44–48% in average frame rates and around 30–37% in 1% lows at 1080p and 1440p using medium settings. With updated testing on ultra settings, the results remained similar.

At 1080p ultra, 9800X3D was 37% faster on average, with 26% stronger 1% lows. Even in heavy action, margins stayed consistent.

At 1440p ultra, the 9800X3D maintained a 39% advantage in averages and 29% in 1% lows. At 4K ultra, both CPUs became GPU-limited, hitting around 140fps with near-identical performance.

AMD, Ryzen 7 9800X3D, Ryzen 7 5800X3D, Battlefield 6, CPU Benchmark Results, NoobFeed

Final Thoughts

Extensive testing has shown that, when CPU-limited at 1080p, Ryzen 7 9800X3D is approximately 35–40% faster than Ryzen 7 5800X3D, with over 40% stronger 1% lows.

Even though the GPU becomes the limiting factor at higher resolutions like 1440p and 4K, 9800X3D still produces greater lows for more fluid gameplay.

Ryzen 7 5800X3D remains highly capable, performing on par with Ryzen 7 9700X and Intel Core Ultra 7265K. At 1440p and 4K with ultra settings, you won’t notice major stuttering or issues. Gameplay is smooth, consistent, and highly playable.

In the end, evaluating Battlefield 6 in multiplayer is never simple, but by benchmarking two identical systems at the same time, we were able to provide consistent, repeatable findings.

The information confirms the expected performance hierarchy while showing that both CPUs deliver excellent experiences, with 9800X3D pulling ahead in CPU-bound conditions.
